WordPress on Azure: Part 3 - Deployment

General

Hello everyone! In today’s blog post, we look into the deployment of our Azure infrastructure and some post-configuration steps.

We use GitHub Actions to deploy our infrastructure.

In the repository, there are two workflow files: one to deploy the infrastructure and one to tear it down.

We will go over some of the elements inside the deploy.yaml workflow.

GitHub Actions

Prerequisites to connect to Azure

• Create an Azure Active Directory application and service principal

• Set up federation and update the repository secrets

• Make sure you give Owner permissions over the subscription (to be more secure you can use PIM)

• According to the documentation, the following must be included in the workflow file:

permissions:
  id-token: write
  contents: read


Connect to Azure and set subscription

- name: Azure Login
  uses: Azure/login@v1
  with:
    client-id: ${{ secrets.AZURE_CLIENT_ID }}
    tenant-id: ${{ secrets.AZURE_TENANT_ID }}
    subscription-id: ${{ secrets.AZURE_SUBSCRIPTION_ID }}

Deploy template

• Before we deploy the template, we first lint and then validate it

- name: Validate template
  working-directory: ${{ github.workspace }}/bicep
  run: |
    az deployment sub validate \
      --name "$DEPLOYMENT_NAME" \
      --location westeurope \
      --template-file main.bicep \
      --parameters "main.parameters.json" \
                    subscription_id="$SUBSCRIPTION_ID" \
                    mysql_admin_password="$ADMIN_PASSWORD" \
                    jumpbox_admin_password="$ADMIN_PASSWORD" \
                    github_runner_object_id="${{ secrets.AZURE_CLIENT_ID }}"

Post-configuration steps

Download database certificate in Kudo environment

• Go to https://.scm.azurewebsites.net/DebugConsole

• Run the following:

cd /home/site/wwwroot && mkdir bin && cd bin
curl <https://cacerts.digicert.com/DigiCertGlobalRootCA.crt.pem> -o DigiCertGlobalRootCA.crt.pem

Import WordPress image to Azure Container Registry

• Allow your IP from the Key Vault’s firewall and give yourself permission to get and list secrets through access policies

• Login to the jumpbox through Bastion using the credentials stored in the Key Vault

• Run the following:

az login --identity
cr_name="{your_registry_name}"
az acr import -n $cr_name --source docker.io/library/wordpress:latest --image wordpress:latest
az acr repository list -n $cr_name

Install WordPress

• Wait 2-3 minutes after you import the image in the ACR

• Go to https://.azurewebsites.net

• Follow the instructions mentioned

Summary

So we deployed our infrastructure and completed the essential post-configuration tasks. In the following and final post, we will configure monitoring and run some tests on our WordPress website.

Next part:

• Part 4: Monitoring & Testing

Previous parts:

• Part 0: Introduction

• Part 1: Architecture

• Part 2: Infrastructure as Code

Related repository: WordPress-on-Azure
